| Place of Origin: | China |
| Brand Name: | Xinland |
Built for professional optical research and controlled engineering applications, this 160W high-power infrared laser system combines a 930nm invisible IR output with adjustable focusing, visible alignment assistance and infrared spot observation.
The system is designed for customers who require a powerful and flexible infrared source for laboratory research, optical experiments, engineering evaluation and specialized industrial testing.
Its adjustable optical system supports different working distances, while the external red alignment laser provides a visible reference for initial positioning. An included night vision unit allows the operator to observe the otherwise invisible infrared spot during system setup and testing.
With a compact 1.3 kg main unit and standard tripod mounting interface, the system can be integrated into fixed laboratory setups or professional field-testing configurations.
The system uses a 160W pump source with approximately 350W electrical power consumption, providing high-power infrared output for demanding professional applications.
Operating at 930nm, the primary infrared output is invisible to the human eye and is intended for specialized optical research and testing environments.
The focusing optics can be manually adjusted according to the required operating distance.
This provides greater flexibility for laboratory experiments and long-distance optical testing where the beam characteristics need to be adjusted for different setups.
Under suitable environmental, focusing and mounting conditions, the system has been tested at distances of up to approximately 100 meters.
Actual usable distance depends on the optical setup, target characteristics, atmospheric conditions, focusing accuracy and mounting stability.
A separate visible red laser provides an easy-to-see reference point during preliminary alignment.
This is especially useful because the primary 930nm infrared beam cannot be seen directly by the human eye.
The supplied night vision unit enables the operator to observe the infrared spot during controlled testing and make alignment adjustments when required.
A standard 1/4-inch threaded mounting interface makes it easy to install the laser system on compatible tripods or fixed support structures.
Stable mounting is particularly important for longer working distances.
| Specification | Details |
|---|---|
| Laser Source Power | 160W |
| Wavelength | 930nm Infrared |
| Beam Visibility | Invisible |
| Electrical Consumption | Approx. 350W |
| Output Type | Direct / Collimated Output |
| Tested Working Distance | Up to Approx. 100m* |
| Focusing Method | Manual Adjustable Focus |
| Alignment Method | External Visible Red Laser |
| IR Observation | Night Vision Unit |
| Input Requirement | Approx. 25V / 13A |
| Mounting Interface | Standard 1/4-inch Thread |
| Main Unit Weight | Approx. 1.3kg |
| Recommended Minimum Distance | 5m |
The stated distance represents testing under specific conditions and should not be interpreted as guaranteed performance for every application.
For applications requiring an independent power source, the system can be supplied with a rechargeable LiFePO₄ battery pack.
Battery specifications:
25.6V rated voltage
6000mAh capacity
XT60 connector
Approx. 1.2m power cable
Approx. 1.3kg battery weight
Actual operating duration varies according to activation frequency, ambient temperature, system temperature and operating conditions.
The system incorporates temperature-control protection to help protect the laser components during high-power operation.
Because operating time is strongly affected by ambient temperature and previous usage, short operating cycles are recommended.
For better thermal management and product life, allow sufficient cooling time between repeated high-power operations.
This 930nm infrared laser system can be considered for:
Optical and photonics research
Infrared system evaluation
Laboratory experiments
Material-response studies
Combustion and ignition research
Engineering verification
Industrial R&D
Infrared observation experiments
Customized optical projects
Professional system integration
Please contact us before ordering if your project requires a specific working distance, power configuration or customized optical setup.
Depending on the selected configuration, the complete system can include:
160W infrared laser main unit
Adjustable focusing optics
External red alignment laser
Night vision observation unit
Remote activation switch
25.6V 6000mAh LiFePO₄ battery
Battery charger
Power connection cable
Removable handle
Battery storage bag
Adjustment tools
Package contents can be configured according to project requirements.
We work with laboratories, engineering companies, research organizations, distributors and industrial customers requiring professional infrared laser solutions.
For project inquiries, please provide your:
Application / Required Working Distance / Quantity / Destination Country / Special Requirements
Based on your requirements, we can confirm the suitable configuration and provide technical information, quotation and estimated lead time.
Need a 160W 930nm infrared laser system for your project?
Contact us with your application and required quantity to receive:
Technical specifications
Available configurations
Accessory options
B2B quotation
Lead time
OEM / customization information
Send your project requirements to get a recommended configuration and quotation.
This is a high-power professional infrared laser system intended only for trained personnel operating in controlled environments.
The 930nm output is invisible and can cause serious eye or skin injury. Appropriate wavelength-rated protective equipment, beam containment, restricted access and professional laser-safety procedures are required.
Never direct the laser toward people, animals, vehicles, aircraft, public areas or uncontrolled environments. Users are responsible for compliance with applicable local laser-safety regulations.
